Compatible Part Number |
SFP-10G-SR |
Brand |
FB-LINK |
Form Factor |
SFP+ |
Data Rate |
10Gb/s |
Wavelength |
850nm |
Max Transmission Reach |
300m |
Connector |
Duplex LC |
Transmit Optical Power |
-7.3 ~ -1 dBm |
Receiver Sensitivity |
< -11.1 dBm |
Extinction Ratio |
> 3 dB |
Power Consumption |
≤ 1W |
Modulation |
NRZ |
Digital Diagnostic Monitoring (DDM) |
Supported |
Laser Type |
VCSEL |
Operating Temperature |
0 ~ 70°C |
Features
◆ Hot-pluggable SFP+ form factor
◆ Max data rate up to 10Gb/s
◆ Power consumption ≤ 1W
◆ Operating temperature: 0°C ~ 70°C
◆ Receiver sensitivity < -11.1dBm
◆ Max reach of 300m over multimode fiber
◆ Compliant with IEEE 802.3ae standard
◆ 10G VCSEL transmitter
◆ Duplex LC connector
◆ I2C management interface
◆ RoHS compliant
