Compatible Part Number |
FBL-SFP-RJ |
Brand |
FB-LINK |
Form Factor |
SFP+ |
Data Rate |
10Gb/s |
Cable Type |
Copper Cable |
Max Transmission Reach |
30m |
Connector |
RJ-45 |
Supported Cable |
Cat5e / Cat6 / Cat6a |
MTBF |
5,000,000 hours |
Application |
Wired LAN |
Package Type |
SFP+ Copper Transceiver |
Power Consumption |
≤ 1.2W |
Digital Diagnostic Monitoring (DDM) |
Not Implemented |
Special Feature |
RX_LOS Indicator |
Operating Temperature |
0 ~ 70°C |
Features
◆ Built-in Marvell chip with a maximum power consumption of 2.3 W
◆ Supports an aggregate bit rate of 10.3125 Gb/s
◆Commercial-grade operating temperature range of -40 °C to 85 °C
◆Tested in target switches to ensure exceptional performance, quality, and reliability
◆Terminated RJ45 connectors enable 10G bandwidth over existing infrastructure
◆Hot-swappable and SFP+ MSA-compliant
◆ Optical interoperability with 10GBASE-X2 interfaces on the same link
◆RoHS compliant
◆ 10G NRZ retiming electrical interface
◆Compliant with IEEE 802.3an and IEEE 802.3az standards
