Product Specifications
Compatible Part Number |
QSFP-40G-ER4 |
Brand |
FB-LINK |
Form Factor |
QSFP+ |
Data Rate |
40Gb/s |
Wavelength |
1310nm |
Max Transmission Reach |
40km |
Connector |
Duplex LC |
Fiber Type |
Single Mode |
Extinction Ratio |
>5.5 dB |
Transmit Optical Power |
-2.7 ~ 4.5 dBm |
Receiver Sensitivity |
< -21.2 dBm |
Power Consumption |
≤ 3.5W |
Digital Diagnostic Monitoring (DDM) |
Supported |
Receiver Type |
APD |
Operating Temperature |
0 ~ 70°C |
Features
◆ Maximum power consumption of 3.5W
◆ Tested on target switches to ensure exceptional performance, quality, and reliability
◆ High-speed electrical interface compliant with the IEEE 802.3ba standard
◆ Compliant with the SFF-8436 and QSFP MSA standards
◆ Compliant with the hot-swappable QSFP+ standard
◆Class 1 FDA laser safety rating and RoHS compliant
◆ Features digital optical monitoring for robust diagnostic capabilities
