Compatible Part Number |
FBL-QSFP-ER4 |
Brand |
FB-LINK |
Form Factor |
QSFP28 |
Data Rate |
100Gb/s |
Wavelength |
1310nm |
Max Transmission Reach |
40km |
Connector |
Duplex LC |
Fiber Type |
Single Mode |
Extinction Ratio |
> 4 dB |
Transmit Optical Power |
-2.5 ~ 2.9 dBm |
Receiver Sensitivity |
< -15 dBm |
Power Consumption |
≤ 5.5W |
Digital Diagnostic Monitoring (DDM) |
Supported |
Receiver Type |
PIN |
Operating Temperature |
0 ~ 70°C |
Features
◆ Hot-swappable QSFP28 MSA form factor
◆Supports a total bit rate of 103.125 Gb/s
◆ Power dissipation <5.5W
◆Commercial operating temperature range: 0°C to 70°C
◆ Single 3.3V power supply
◆ Maximum link length of 40 km over single-mode fiber (SMF)
◆ Compliant with the IEEE 802.3ba standard
◆4x25G EML LAN-WDM transmitter
◆ 4x25G NRZ retiming CAUI-4 electrical interface
◆ Duplex LC connector
◆I2C management interface
◆ Compliant with RoHS regulations
